◦Includes a compact scale built in while keeping the installation space the same as that of the equivalent open loop OSMS series.
|
MODEL NUMBER |
Resolution(um/pulse) |
MOTION RANGE(mm) |
LOAD CAPACITY |
PRICE(￥) |
|
OSMS(CS)20-35(X) |
Full:2, Half:1 |
35 |
78.4N(8.0kgf) |
168,000 |
|
OSMS(CS)20-35(X)-M6 |
Full:2, Half:1 |
35 |
78.4N(8.0kgf) |
168,000 |
|
OSMS(CS)20-35(X)-INCH |
Full:2, Half:1 |
35 |
78.4N(8.0kgf) |
168,000 |
|
OSMS(CS)20-85(X) |
Full:2, Half:1 |
85 |
78.4N(8.0kgf) |
178,000 |
|
OSMS(CS)20-85(X)-M6 |
Full:2, Half:1 |
85 |
78.4N(8.0kgf) |
178,000 |
|
OSMS(CS)20-85(X)-INCH |
Full:2, Half:1 |
85 |
78.4N(8.0kgf) |
178,000 |
|
OSMS(CS)26-100(X) |
Full:2, Half:1 |
100 |
117N(12kgf) |
208,000 |
|
OSMS(CS)26-100(X)-M6 |
Full:2, Half:1 |
100 |
117N(12kgf) |
208,000 |
|
OSMS(CS)26-100(X)-INCH |
Full:2, Half:1 |
100 |
117N(12kgf) |
208,000 |
|
OSMS(CS)26-200(X) |
Full:2, Half:1 |
200 |
117N(12kgf) |
226,000 |
|
OSMS(CS)26-200(X)-M6 |
Full:2, Half:1 |
200 |
117N(12kgf) |
226,000 |
|
OSMS(CS)26-200(X)-INCH |
Full:2, Half:1 |
200 |
117N(12kgf) |
226,000 |
|
OSMS(CS)33-300(X) |
Full:20, Half:10 |
300 |
196N(20.0kgf) |
398,000 |
|
OSMS(CS)33-300(X)-M6 |
Full:20, Half:10 |
300 |
196N(20.0kgf) |
398,000 |
|
OSMS(CS)33-300(X)-INCH |
Full:20, Half:10 |
300 |
196N(20.0kgf) |
398,000 |
|
OSMS(CS)33-500(X) |
Full:20, Half:10 |
500 |
196N(20.0kgf) |
438,000 |
|
OSMS(CS)33-500(X)-M6 |
Full:20, Half:10 |
500 |
196N(20.0kgf) |
438,000 |
|
OSMS(CS)33-500(X)-INCH |
Full:20, Half:10 |
500 |
196N(20.0kgf) |
438,000 |
