psi

Model

Price

〔￥〕

Objective Lens type

Objective Lens Length A [mm]

Compatible Incidence Beam diameter (1/e2 ) φ [mm]

Pinhole Diameter

φ

[μm]

Pinhole XY Adjustment Range

[mm]

Objective Lens Front & Back Adjustment Range [mm]

Pinhole XY Coarse Resolution [mm/rotation]

Pinhole XY Scale MIN Reading [mm/DIV]

Objective Lens Front & Back Scale Min Reading [mm/DIV]

Weight

[kg]

SFB-16DMRO-OBL10-25

143,500

OBL-10-A

30.5

1.0

25

±2

±3

0.5

0.0025

0.01

0.6

SFB-16DMRO-OBL20-25

145,500

OBL-20-A

35.2

0.6

25

±2

±3

0.5

0.0025

0.01

0.6

SFB-16DMRO-OBL40-25

147,500

OBL-40-A

36.5

0.3

25

±2

±3

0.5

0.0025

0.01

0.6
